The Global Professional 70MHz to L Band Frequency Converter enables monitoring of a 70 or 140 MHz bus of an uplink and downlink stations using an inexpensive L band receiver.
Click here for DATA SHEET
The unit works as an upconverter, but also allows for downconversion in reverse.
The unit is available in a number of fixed LO frequencies offering a choice of L band output frequencies and as either 50 or 75 ohm impedance.
The unit is externally powered via L band Receiver on output port.
This product is mainly designed for monitoring and therefore has no image filtering installed.
